Current price of 207534-8 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]
Type | Description |
---|---|
Series: | Metrimate |
Package: | Tray |
Part Status: | Active |
Connector Type: | Header |
Contact Type: | Female Socket |
Style: | Board to Cable/Wire |
Number of Positions: | 36 |
Number of Positions Loaded: | All |
Pitch - Mating: | 0.197" (5.00mm) |
Number of Rows: | 4 |
Row Spacing - Mating: | 0.197" (5.00mm) |
Mounting Type: | Through Hole |
Termination: | Solder |
Fastening Type: | Latch Holder |
Contact Finish - Mating: | Tin-Lead |
Contact Finish Thickness - Mating: | 150.0µin (3.81µm) |
Insulation Color: | Black, Red |
Insulation Height: | 0.565" (14.35mm) |
Contact Length - Post: | 0.181" (4.60mm) |
Operating Temperature: | -55°C ~ 130°C |
Material Flammability Rating: | UL94 V-0 |
Contact Finish - Post: | Tin |
Mated Stacking Heights: | - |
Ingress Protection: | - |
Features: | Mounting Flange |
Current Rating (Amps): | 7.5A |
Voltage Rating: | 600V |
