| Type | Description |
|---|---|
| Series: | Dubox™ |
| Package: | Tube |
| Part Status: | Active |
| Connector Type: | Receptacle, Bottom or Top Entry |
| Contact Type: | Female Socket |
| Style: | Board to Board |
| Number of Positions: | 12 |
| Number of Positions Loaded: | All |
| Pitch - Mating: | 0.100" (2.54mm) |
| Number of Rows: | 2 |
| Row Spacing - Mating: | 0.100" (2.54mm) |
| Mounting Type: | Surface Mount |
| Termination: | Solder |
| Fastening Type: | Push-Pull |
| Contact Finish - Mating: | Gold |
| Contact Finish Thickness - Mating: | 30.0µin (0.76µm) |
| Insulation Color: | Gray |
| Insulation Height: | 0.275" (6.99mm) |
| Contact Length - Post: | - |
| Operating Temperature: | - |
| Material Flammability Rating: | UL94 V-0 |
| Contact Finish - Post: | Tin |
| Mated Stacking Heights: | 10.81mm |
| Ingress Protection: | - |
| Features: | Pick and Place |
| Current Rating (Amps): | - |
| Voltage Rating: | - |
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ||
| 608 |
Current price of 89898-306BLF is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@Vigorcomp.com
