| Type | Description |
|---|---|
| Series: | har-flex® |
| Package: | Tape & Reel (TR)Cut Tape (CT) |
| Part Status: | Active |
| Connector Type: | Receptacle |
| Contact Type: | Female Socket |
| Style: | Board to Board or Cable |
| Number of Positions: | 68 |
| Number of Positions Loaded: | All |
| Pitch - Mating: | 0.050" (1.27mm) |
| Number of Rows: | 2 |
| Row Spacing - Mating: | 0.050" (1.27mm) |
| Mounting Type: | Surface Mount |
| Termination: | Solder |
| Fastening Type: | Push-Pull |
| Contact Finish - Mating: | Gold |
| Contact Finish Thickness - Mating: | - |
| Insulation Color: | Black |
| Insulation Height: | 0.356" (9.05mm) |
| Contact Length - Post: | - |
| Operating Temperature: | -55°C ~ 125°C |
| Material Flammability Rating: | UL94 V-0 |
| Contact Finish - Post: | Tin |
| Mated Stacking Heights: | 10.8mm ~ 13.8mm |
| Ingress Protection: | - |
| Features: | Board Guide, Pick and Place, Solder Retention |
| Current Rating (Amps): | - |
| Voltage Rating: | - |
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ||
| 280 | ||
| 560 | ||
| 840 | ||
| 1400 | ||
| 1960 |
Current price of 15220682601000 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@Vigorcomp.com
