5120-B7A2PL

Part No :: 5120-B7A2PL

Manufacturer: 3M

VIGOR # :: 3134221

Description: CONN RCPT 20POS 0.1 GOLD PCB R/A

Catalog: Rectangular Connectors - Headers, Receptacles, Female Sockets

DataSheet: 5120-B7A2PL PDF

Country of origin: -

Date code: -

5120-B7A2PL Specifications

Type	Description
Series:	5100
Package:	Bulk
Part Status:	Active
Connector Type:	Receptacle
Contact Type:	Female Socket
Style:	Board to Board or Cable
Number of Positions:	20
Number of Positions Loaded:	All
Pitch - Mating:	0.100" (2.54mm)
Number of Rows:	2
Row Spacing - Mating:	0.100" (2.54mm)
Mounting Type:	Through Hole, Right Angle
Termination:	Solder
Fastening Type:	Push-Pull
Contact Finish - Mating:	Gold
Contact Finish Thickness - Mating:	30.0µin (0.76µm)
Insulation Color:	Gray
Insulation Height:	0.350" (8.89mm)
Contact Length - Post:	0.102" (2.60mm)
Operating Temperature:	-55°C ~ 105°C
Material Flammability Rating:	UL94 V-0
Contact Finish - Post:	Gold
Mated Stacking Heights:	-
Ingress Protection:	-
Features:	Mounting Flange, Polarizing Key
Current Rating (Amps):	1A
Voltage Rating:	1000V
