| Type | Description |
|---|---|
| Series: | AMPMODU 50/50 Grid |
| Package: | Tube |
| Part Status: | Active |
| Connector Type: | Receptacle |
| Contact Type: | Female Socket |
| Style: | Board to Board or Cable |
| Number of Positions: | 60 |
| Number of Positions Loaded: | All |
| Pitch - Mating: | 0.050" (1.27mm) |
| Number of Rows: | 2 |
| Row Spacing - Mating: | 0.050" (1.27mm) |
| Mounting Type: | Surface Mount |
| Termination: | Solder |
| Fastening Type: | Push-Pull |
| Contact Finish - Mating: | Gold |
| Contact Finish Thickness - Mating: | 30.0µin (0.76µm) |
| Insulation Color: | Black |
| Insulation Height: | 0.187" (4.75mm) |
| Contact Length - Post: | - |
| Operating Temperature: | -65°C ~ 105°C |
| Material Flammability Rating: | - |
| Contact Finish - Post: | Tin-Lead |
| Mated Stacking Heights: | 6.35mm, 8.13mm, 9.91mm |
| Ingress Protection: | - |
| Features: | Board Lock |
| Current Rating (Amps): | - |
| Voltage Rating: | - |
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ||
| 12 | ||
| 108 | ||
| 504 | ||
| 1008 |
Current price of 104652-6 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@Vigorcomp.com
