1503560000

1503560000

Image is for reference,
please contact us to get the real picture

Part No :

1503560000

Manufacturer
Weidmuller
Description
TERM BLOCK PLUG 19POS STR 5.08MM
Catalog
Terminal Blocks - Headers, Plugs and Sockets
Shipped from
HK warehouse
Expected Shipping Date
Oct 25 - Oct 29 2025
DataSheet
1503560000 PDF
Availability
0 pieces
Unit Price
$0.00000

Current price of 1503560000 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

1503560000 Specifications
Type Description
Series:Omnimate BL
Package:Bulk
Part Status:Obsolete
Type:Plug, Female Sockets
Number of Positions:19
Positions Per Level:19
Number of Levels:1
Pitch:0.200" (5.08mm)
Header Orientation:-
Plug Wire Entry:180°
Termination Style:Screw - TOP Clamp
Mounting Type:Free Hanging (In-Line)
Current - IEC:17A
Voltage - IEC:400 V
Current - UL:10 A
Voltage - UL:300 V
Wire Gauge or Range - AWG:14-26 AWG
Wire Gauge or Range - mm²:0.2-2.5mm²
Color:Orange
Operating Temperature:-
Contact Mating Finish:Tin
Features:Retention Latches (Non-Wire Side)
