H9022-01

Part No :: H9022-01

Manufacturer: Harwin

Description: TERM TURRET SINGLE L=7.65MM TIN

Catalog: Terminals - Turret Connectors

DataSheet: H9022-01 PDF

Availability: 0 pieces

Current price of H9022-01 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

H9022-01 Specifications

Type	Description
Series:	-
Package:	Bulk
Part Status:	Obsolete
Terminal Type:	Single End
Number of Turrets:	Triple
Length - Above Board:	0.301" (7.65mm)
Length - Below Flange:	0.156" (3.96mm)
Length - Overall:	0.457" (11.61mm)
Mounting Type:	Through Hole
Termination:	Swage
Flange Diameter:	0.125" (3.18mm)
Diameter - Turret Head:	0.093" (2.36mm)
Staking Side OD:	-
Staking Side ID:	0.064" (1.63mm)
Mounting Hole Diameter:	0.092" ~ 0.096" (2.34mm ~ 2.44mm)
Board Thickness:	0.126" (3.20mm)
Contact Material:	Brass Alloy
Contact Finish:	Tin
Contact Finish Thickness:	-
Insulation:	Non-Insulated
