520R15HA16M3690

Part No :: 520R15HA16M3690

Manufacturer: CTS Corporation

VIGOR # :: 2271449

Description: XTAL OSC VCTCXO 16.3690MHZ SNWV

Catalog: Oscillators

DataSheet: 520R15HA16M3690 PDF

Country of origin: -

Date code: -

520R15HA16M3690 Specifications

Type	Description
Series:	520
Package:	Tape & Reel (TR)
Part Status:	Active
Base Resonator:	Crystal
Type:	VCTCXO
Frequency:	16.369 MHz
Function:	-
Output:	Clipped Sine Wave
Voltage - Supply:	3V
Frequency Stability:	±1.5ppm
Absolute Pull Range (APR):	-
Operating Temperature:	-10°C ~ 60°C
Spread Spectrum Bandwidth:	-
Current - Supply (Max):	2mA
Ratings:	-
Mounting Type:	Surface Mount
Package / Case:	4-SMD, No Lead
Size / Dimension:	0.098" L x 0.079" W (2.50mm x 2.00mm)
Height - Seated (Max):	0.031" (0.80mm)
