HMC1166LP5ETR

Part No :: HMC1166LP5ETR

Manufacturer: Linear Technology (Analog Devices, Inc.)

Description: VCO 6.0075GHZ/12.015GHZ 2-13V

Catalog: VCOs (Voltage Controlled Oscillators)

DataSheet: HMC1166LP5ETR PDF

Availability: 0 pieces

Current price of HMC1166LP5ETR is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

HMC1166LP5ETR Specifications

Type	Description
Series:	HMC1166
Package:	Tape & Reel (TR)
Part Status:	Active
Frequency Range:	5.705 ~ 6.31GHz, 11.41 ~ 12.62GHz
Frequency - Center:	6.0075GHz, 12.015GHz
Voltage - Supply:	5V
Tuning Voltage (VDC):	2 V ~ 13.0 V
2nd Harmonic, Typ (dBc):	20
Icc Max:	270mA
Pushing (MHz/V):	5
Power (dBm):	4.5±4.5, 11±4
Phase Noise Typ (dBc/Hz):	-89
Operating Temperature:	-40°C ~ 85°C
Package / Case:	32-VFQFN Exposed Pad, CSP
Size / Dimension:	0.197" L x 0.197" W (5.00mm x 5.00mm)
Height:	0.039" (1.00mm)

Please confirm the specifications of the products when ordering.
