HMC1167LP5ETR

Part No :: HMC1167LP5ETR

Manufacturer: Linear Technology (Analog Devices, Inc.)

Description: VCO 6.375/12.75GHZ 2-13V 5X5MM

Catalog: VCOs (Voltage Controlled Oscillators)

DataSheet: HMC1167LP5ETR PDF

Availability: 0 pieces

Current price of HMC1167LP5ETR is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

HMC1167LP5ETR Specifications

Type	Description
Series:	HMC1167
Package:	Tape & Reel (TR)
Part Status:	Active
Frequency Range:	6.085 ~ 6.665GHz, 12.17 ~ 13.33GHz
Frequency - Center:	6.375GHz, 12.75GHz
Voltage - Supply:	5V
Tuning Voltage (VDC):	2 V ~ 13.0 V
2nd Harmonic, Typ (dBc):	20
Icc Max:	250mA
Pushing (MHz/V):	2
Power (dBm):	3.5±4.5, 11±4
Phase Noise Typ (dBc/Hz):	-86
Operating Temperature:	-40°C ~ 85°C
Package / Case:	32-VFQFN Exposed Pad, CSP
Size / Dimension:	0.197" L x 0.197" W (5.00mm x 5.00mm)
Height:	0.039" (1.00mm)

Please confirm the specifications of the products when ordering.
