SH-132

Image is for reference,
please contact us to get the real picture

Part No :: SH-132

Manufacturer: KEMET

Description: CMC TROID, NI-ZN, 2.6UH, TH UL94

Catalog: Common Mode Chokes

DataSheet: SH-132 PDF

Availability: 158 pieces

Unit Price: ~~$3.30000~~

Current price of SH-132 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

SH-132 Specifications

Type	Description
Series:	SH
Package:	Bulk
Part Status:	Active
Filter Type:	Power Line
Number of Lines:	2
Impedance @ Frequency:	-
Inductance @ Frequency:	-
Frequency Coupled to Inductance @ Frequency:	-
Current Rating (Max):	2.4A
DC Resistance (DCR) (Max):	51mOhm
Voltage Rating - DC:	50V
Voltage Rating - AC:	-
Operating Temperature:	-25°C ~ 60°C
Ratings:	-
Approval Agency:	-
Features:	-
Mounting Type:	Through Hole
Size / Dimension:	0.394" L x 0.354" W (10.00mm x 9.00mm)
Height (Max):	0.413" (10.50mm)
Package / Case:	Vertical, 6 PC Pin
