DR331-513AE

Image is for reference,
please contact us to get the real picture

Part No :: DR331-513AE

Manufacturer: J.W. Miller / Bourns

Description: CMC 51UH 500MA 2LN SMD

Catalog: Common Mode Chokes

DataSheet: DR331-513AE PDF

Availability: 194744 pieces

Unit Price: ~~$1.04000~~

Current price of DR331-513AE is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

DR331-513AE Specifications

Type	Description
Series:	DR331
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Filter Type:	Signal Line
Number of Lines:	2
Impedance @ Frequency:	-
Inductance @ Frequency:	51 µH @ 100 kHz
Frequency Coupled to Inductance @ Frequency:	-
Current Rating (Max):	500mA
DC Resistance (DCR) (Max):	300mOhm
Voltage Rating - DC:	80V
Voltage Rating - AC:	42V
Operating Temperature:	-40°C ~ 135°C
Ratings:	-
Approval Agency:	-
Features:	-
Mounting Type:	Surface Mount
Size / Dimension:	0.287" L x 0.213" W (7.30mm x 5.40mm)
Height (Max):	0.197" (5.00mm)
Package / Case:	Horizontal, 4 Flat Lead
