Part No :: 23Z109SMNL

Manufacturer: PulseLarsen Antenna

VIGOR # :: 4966446

Description: COMMON MODE CHOKE 10LN SMD

Catalog: Common Mode Chokes

DataSheet: 23Z109SMNL PDF

Country of origin: -

Date code: -

23Z109SMNL Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Active
Filter Type:	Signal Line
Number of Lines:	10
Impedance @ Frequency:	-
Inductance @ Frequency:	-
Frequency Coupled to Inductance @ Frequency:	-
Current Rating (Max):	-
DC Resistance (DCR) (Max):	200mOhm
Voltage Rating - DC:	-
Voltage Rating - AC:	-
Operating Temperature:	-
Ratings:	-
Approval Agency:	-
Features:	-
Mounting Type:	Surface Mount
Size / Dimension:	0.600" L x 0.295" W (15.24mm x 7.50mm)
Height (Max):	0.220" (5.59mm)
Package / Case:	20-SOIC (0.295", 7.50mm Width)
