74485542101

Image is for reference,
please contact us to get the real picture

Part No :: 74485542101

Manufacturer: Würth Elektronik Midcom

Description: INDUCT ARRAY 2 COIL 10UH SMD

Catalog: Arrays, Signal Transformers

DataSheet: 74485542101 PDF

Availability: 144 pieces

Unit Price: ~~$12.45000~~

Current price of 74485542101 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

74485542101 Specifications

Type	Description
Series:	WE-CFWI
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Number of Coils:	2
Inductance - Connected In Parallel:	10 µH
Inductance - Connected In Series:	-
Tolerance:	±20%
Current Rating - Parallel:	11.5 A
Current Rating - Series:	-
Current Saturation - Parallel:	22 A
Current Saturation - Series:	-
DC Resistance (DCR) - Parallel:	11mOhm
DC Resistance (DCR) - Series:	-
Shielding:	Shielded
Ratings:	-
Operating Temperature:	-40°C ~ 150°C
Mounting Type:	Surface Mount
Package / Case:	4-SMD
Size / Dimension:	0.827" L x 0.728" W (21.00mm x 18.50mm)
Height:	0.531" (13.50mm)

Please confirm the specifications of the products when ordering.
