744873001

Image is for reference,
please contact us to get the real picture

Part No :: 744873001

Manufacturer: Würth Elektronik Midcom

Description: INDUCT ARRAY 2 COIL 1.5UH SMD

Catalog: Arrays, Signal Transformers

DataSheet: 744873001 PDF

Availability: 0 pieces

Unit Price: ~~$1.80900~~

Current price of 744873001 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

744873001 Specifications

Type	Description
Series:	WE-DD
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Number of Coils:	2
Inductance - Connected In Parallel:	1.5 µH
Inductance - Connected In Series:	6 µH
Tolerance:	±30%
Current Rating - Parallel:	6.25 A
Current Rating - Series:	3.125 A
Current Saturation - Parallel:	18 A
Current Saturation - Series:	9 A
DC Resistance (DCR) - Parallel:	15mOhm Max
DC Resistance (DCR) - Series:	-
Shielding:	Shielded
Ratings:	-
Operating Temperature:	-40°C ~ 125°C
Mounting Type:	Surface Mount
Package / Case:	Nonstandard
Size / Dimension:	0.492" L x 0.492" W (12.50mm x 12.50mm)
Height:	0.335" (8.50mm)

Please confirm the specifications of the products when ordering.
