74485540120

Image is for reference,
please contact us to get the real picture

Part No :: 74485540120

Manufacturer: Würth Elektronik Midcom

Description: INDUCT ARRAY 2 COIL 1.2UH SMD

Catalog: Arrays, Signal Transformers

DataSheet: 74485540120 PDF

Availability: 0 pieces

Unit Price: ~~$4.43500~~

Current price of 74485540120 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

74485540120 Specifications

Type	Description
Series:	WE-CFWI
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Number of Coils:	2
Inductance - Connected In Parallel:	1.2 µH
Inductance - Connected In Series:	4.8 µH
Tolerance:	±20%
Current Rating - Parallel:	23 A
Current Rating - Series:	11.5 A
Current Saturation - Parallel:	47 A
Current Saturation - Series:	23.5 A
DC Resistance (DCR) - Parallel:	3.84mOhm Max
DC Resistance (DCR) - Series:	-
Shielding:	Shielded
Ratings:	-
Operating Temperature:	-40°C ~ 150°C
Mounting Type:	Surface Mount
Package / Case:	4-SMD
Size / Dimension:	0.610" L x 0.520" W (15.50mm x 13.20mm)
Height:	0.413" (10.50mm)
