DRQ74-820-R

Part No :: DRQ74-820-R

Manufacturer: PowerStor (Eaton)

Description: INDUCT ARRAY 2 COIL 80.95UH SMD

Catalog: Arrays, Signal Transformers

DataSheet: DRQ74-820-R PDF

Availability: 0 pieces

Unit Price: ~~$0.85715~~

Current price of DRQ74-820-R is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

DRQ74-820-R Specifications

Type	Description
Series:	DRQ
Package:	Tape & Reel (TR)
Part Status:	Active
Number of Coils:	2
Inductance - Connected In Parallel:	80.95 µH
Inductance - Connected In Series:	323.8 µH
Tolerance:	±20%
Current Rating - Parallel:	910 mA
Current Rating - Series:	453 mA
Current Saturation - Parallel:	1.11 A
Current Saturation - Series:	550 mA
DC Resistance (DCR) - Parallel:	345mOhm
DC Resistance (DCR) - Series:	1.38Ohm
Shielding:	Shielded
Ratings:	-
Operating Temperature:	-40°C ~ 125°C
Mounting Type:	Surface Mount
Package / Case:	Nonstandard
Size / Dimension:	0.299" L x 0.299" W (7.60mm x 7.60mm)
Height:	0.175" (4.45mm)
