IMC1812ES101K

Part No :: IMC1812ES101K

Manufacturer: Vishay / Dale

Description: FIXED IND 100UH 110MA 8 OHM SMD

Catalog: Fixed Inductors

DataSheet: IMC1812ES101K PDF

Availability: 0 pieces

Current price of IMC1812ES101K is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

IMC1812ES101K Specifications

Type	Description
Series:	IMC-1812
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Type:	Wirewound
Material - Core:	Iron Powder
Inductance:	100 µH
Tolerance:	±10%
Current Rating (Amps):	110 mA
Current - Saturation (Isat):	-
Shielding:	Unshielded
DC Resistance (DCR):	8Ohm Max
Q @ Freq:	40 @ 790kHz
Frequency - Self Resonant:	8MHz
Ratings:	-
Operating Temperature:	-55°C ~ 125°C
Inductance Frequency - Test:	790 kHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	1812 (4532 Metric)
Supplier Device Package:	1812
Size / Dimension:	0.177" L x 0.126" W (4.50mm x 3.20mm)
Height - Seated (Max):	0.134" (3.40mm)
