CIL10S180KNC

Image is for reference,
please contact us to get the real picture

Part No :: CIL10S180KNC

Manufacturer: Samsung Electro-Mechanics

Description: FIXED IND 18UH 1MA 1.85OHM SMD

Catalog: Fixed Inductors

DataSheet: CIL10S180KNC PDF

Availability: 0 pieces

Unit Price: ~~$0.00897~~

Current price of CIL10S180KNC is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

CIL10S180KNC Specifications

Type	Description
Series:	CIL10
Package:	Tape & Reel (TR)
Part Status:	Obsolete
Type:	-
Material - Core:	Ferrite
Inductance:	18 µH
Tolerance:	±10%
Current Rating (Amps):	1 mA
Current - Saturation (Isat):	-
Shielding:	Shielded
DC Resistance (DCR):	1.85Ohm Max
Q @ Freq:	20 @ 1MHz
Frequency - Self Resonant:	13MHz
Ratings:	-
Operating Temperature:	-40°C ~ 85°C
Inductance Frequency - Test:	1 MHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	0603 (1608 Metric)
Supplier Device Package:	0603 (1608 Metric)
Size / Dimension:	0.063" L x 0.031" W (1.60mm x 0.80mm)
Height - Seated (Max):	0.037" (0.95mm)
