ELL-4GG150M

Image is for reference,
please contact us to get the real picture

Part No :: ELL-4GG150M

Manufacturer: Panasonic

Description: FIXED IND 15UH 580MA 500 MOHM

Catalog: Fixed Inductors

DataSheet: ELL-4GG150M PDF

Availability: 298 pieces

Unit Price: ~~$0.55000~~

Current price of ELL-4GG150M is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

ELL-4GG150M Specifications

Type	Description
Series:	G
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Obsolete
Type:	Wirewound
Material - Core:	-
Inductance:	15 µH
Tolerance:	±20%
Current Rating (Amps):	580 mA
Current - Saturation (Isat):	700mA
Shielding:	Shielded
DC Resistance (DCR):	500mOhm
Q @ Freq:	-
Frequency - Self Resonant:	-
Ratings:	-
Operating Temperature:	-
Inductance Frequency - Test:	100 kHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	Nonstandard
Supplier Device Package:	-
Size / Dimension:	0.150" L x 0.150" W (3.80mm x 3.80mm)
Height - Seated (Max):	0.055" (1.40mm)
