2300LL-180-V-RC

Part No :: 2300LL-180-V-RC

Manufacturer: J.W. Miller / Bourns

Description: FIXED IND 18UH 18.5A 5 MOHM TH

Catalog: Fixed Inductors

DataSheet: 2300LL-180-V-RC PDF

Availability: 0 pieces

Current price of 2300LL-180-V-RC is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

2300LL-180-V-RC Specifications

Type	Description
Series:	2300LL
Package:	Bulk
Part Status:	Active
Type:	Toroidal
Material - Core:	Sendust
Inductance:	18 µH
Tolerance:	±15%
Current Rating (Amps):	18.5 A
Current - Saturation (Isat):	-
Shielding:	Shielded
DC Resistance (DCR):	5mOhm Max
Q @ Freq:	-
Frequency - Self Resonant:	-
Ratings:	-
Operating Temperature:	-55°C ~ 125°C
Inductance Frequency - Test:	1 kHz
Features:	-
Mounting Type:	Through Hole
Package / Case:	Radial, Vertical (Open)
Supplier Device Package:	-
Size / Dimension:	1.280" Dia x 0.650" W (32.51mm x 16.51mm)
Height - Seated (Max):	-
