LB2518T220M

Part No :: LB2518T220M

Manufacturer: TAIYO YUDEN

Description: FIXED IND 22UH 115MA 500 MOHM

Catalog: Fixed Inductors

DataSheet: LB2518T220M PDF

Availability: 1962 pieces

Current price of LB2518T220M is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

LB2518T220M Specifications

Type	Description
Series:	LB
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Type:	Wirewound
Material - Core:	-
Inductance:	22 µH
Tolerance:	±20%
Current Rating (Amps):	115 mA
Current - Saturation (Isat):	-
Shielding:	Unshielded
DC Resistance (DCR):	500mOhm
Q @ Freq:	-
Frequency - Self Resonant:	19MHz
Ratings:	-
Operating Temperature:	-25°C ~ 105°C
Inductance Frequency - Test:	2.52 MHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	1007 (2518 Metric)
Supplier Device Package:	1007 (2518 Metric)
Size / Dimension:	0.098" L x 0.071" W (2.50mm x 1.80mm)
Height - Seated (Max):	0.079" (2.00mm)
