PM105-120M-RC

Part No :: PM105-120M-RC

Manufacturer: J.W. Miller / Bourns

Description: FIXED IND 12UH 2.45A 70 MOHM SMD

Catalog: Fixed Inductors

DataSheet: PM105-120M-RC PDF

Availability: 0 pieces

Current price of PM105-120M-RC is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

PM105-120M-RC Specifications

Type	Description
Series:	PM105
Package:	Tape & Reel (TR)
Part Status:	Active
Type:	Wirewound
Material - Core:	Ferrite
Inductance:	12 µH
Tolerance:	±20%
Current Rating (Amps):	2.45 A
Current - Saturation (Isat):	4.5A
Shielding:	Unshielded
DC Resistance (DCR):	70mOhm
Q @ Freq:	30 @ 2.52MHz
Frequency - Self Resonant:	20MHz
Ratings:	-
Operating Temperature:	-40°C ~ 125°C
Inductance Frequency - Test:	1 kHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	Nonstandard
Supplier Device Package:	-
Size / Dimension:	0.386" L x 0.386" W (9.80mm x 9.80mm)
Height - Seated (Max):	0.228" (5.80mm)

Please confirm the specifications of the products when ordering.
