SDR0805-181KL

Part No :: SDR0805-181KL

Manufacturer: J.W. Miller / Bourns

Description: FIXED IND 180UH 510MA 770MOHM SM

Catalog: Fixed Inductors

DataSheet: SDR0805-181KL PDF

Availability: 240 pieces

Current price of SDR0805-181KL is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

SDR0805-181KL Specifications

Type	Description
Series:	SDR0805
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Type:	Wirewound
Material - Core:	Ferrite
Inductance:	180 µH
Tolerance:	±10%
Current Rating (Amps):	510 mA
Current - Saturation (Isat):	800mA
Shielding:	Unshielded
DC Resistance (DCR):	770mOhm Max
Q @ Freq:	12 @ 796kHz
Frequency - Self Resonant:	5MHz
Ratings:	-
Operating Temperature:	-40°C ~ 125°C
Inductance Frequency - Test:	1 kHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	Nonstandard
Supplier Device Package:	-
Size / Dimension:	0.307" L x 0.307" W (7.80mm x 7.80mm)
Height - Seated (Max):	0.209" (5.30mm)
