B82422A1102K108

Part No :: B82422A1102K108

Manufacturer: TDK EPCOS

Description: FIXED IND 1UH 380MA 340 MOHM SMD

Catalog: Fixed Inductors

DataSheet: B82422A1102K108 PDF

Availability: 0 pieces

Current price of B82422A1102K108 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

B82422A1102K108 Specifications

Type	Description
Series:	SIMID
Package:	Tape & Reel (TR)
Part Status:	Active
Type:	Wirewound
Material - Core:	Ferrite
Inductance:	1 µH
Tolerance:	±10%
Current Rating (Amps):	380 mA
Current - Saturation (Isat):	-
Shielding:	Unshielded
DC Resistance (DCR):	340mOhm Max
Q @ Freq:	20 @ 7.96MHz
Frequency - Self Resonant:	320MHz
Ratings:	AEC-Q200
Operating Temperature:	-55°C ~ 125°C
Inductance Frequency - Test:	1 MHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	2-SMD, J-Lead
Supplier Device Package:	1210 (3225 Metric)
Size / Dimension:	0.126" L x 0.098" W (3.20mm x 2.50mm)
Height - Seated (Max):	0.083" (2.10mm)
