SDR0604-8R2ML

Part No :: SDR0604-8R2ML

Manufacturer: J.W. Miller / Bourns

Description: FIXED IND 8.2UH 1.5A 90 MOHM SMD

Catalog: Fixed Inductors

DataSheet: SDR0604-8R2ML PDF

Availability: 1090 pieces

Current price of SDR0604-8R2ML is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

SDR0604-8R2ML Specifications

Type	Description
Series:	SDR0604
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Type:	Wirewound
Material - Core:	Ferrite
Inductance:	8.2 µH
Tolerance:	±20%
Current Rating (Amps):	1.5 A
Current - Saturation (Isat):	2.3A
Shielding:	Unshielded
DC Resistance (DCR):	90mOhm Max
Q @ Freq:	20 @ 7.96MHz
Frequency - Self Resonant:	26MHz
Ratings:	-
Operating Temperature:	-40°C ~ 125°C
Inductance Frequency - Test:	1 kHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	Nonstandard
Supplier Device Package:	-
Size / Dimension:	0.228" L x 0.228" W (5.80mm x 5.80mm)
Height - Seated (Max):	0.189" (4.80mm)

Please confirm the specifications of the products when ordering.
