SRP0520-R68K

Part No :: SRP0520-R68K

Manufacturer: J.W. Miller / Bourns

Description: FIXED IND 680NH 10.7A 9 MOHM SMD

Catalog: Fixed Inductors

DataSheet: SRP0520-R68K PDF

Availability: 2770 pieces

Current price of SRP0520-R68K is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

SRP0520-R68K Specifications

Type	Description
Series:	SRP0520
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Type:	-
Material - Core:	Metal
Inductance:	680 nH
Tolerance:	±10%
Current Rating (Amps):	10.7 A
Current - Saturation (Isat):	18A
Shielding:	Shielded
DC Resistance (DCR):	9mOhm Max
Q @ Freq:	17 @ 25.2MHz
Frequency - Self Resonant:	56MHz
Ratings:	-
Operating Temperature:	-40°C ~ 125°C
Inductance Frequency - Test:	100 kHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	Nonstandard
Supplier Device Package:	-
Size / Dimension:	0.213" L x 0.201" W (5.40mm x 5.10mm)
Height - Seated (Max):	0.079" (2.00mm)

Please confirm the specifications of the products when ordering.
