IMC1812EB22NM

Part No :: IMC1812EB22NM

Manufacturer: Vishay / Dale

Description: FIXED IND 22NH 450MA 200 MOHM

Catalog: Fixed Inductors

DataSheet: IMC1812EB22NM PDF

Availability: 0 pieces

Current price of IMC1812EB22NM is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

IMC1812EB22NM Specifications

Type	Description
Series:	IMC-1812
Package:	Bulk
Part Status:	Active
Type:	Wirewound
Material - Core:	Non-Magnetic
Inductance:	22 nH
Tolerance:	±20%
Current Rating (Amps):	450 mA
Current - Saturation (Isat):	-
Shielding:	Unshielded
DC Resistance (DCR):	200mOhm Max
Q @ Freq:	50 @ 50MHz
Frequency - Self Resonant:	1GHz
Ratings:	-
Operating Temperature:	-55°C ~ 125°C
Inductance Frequency - Test:	50 MHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	1812 (4532 Metric)
Supplier Device Package:	1812
Size / Dimension:	0.177" L x 0.126" W (4.50mm x 3.20mm)
Height - Seated (Max):	0.134" (3.40mm)

Please confirm the specifications of the products when ordering.
