LQH2HPZ3R3MGRL

Part No :: LQH2HPZ3R3MGRL

Manufacturer: TOKO / Murata

Description: FIXED IND 3.3UH 1.1A 270 MOHM

Catalog: Fixed Inductors

DataSheet: LQH2HPZ3R3MGRL PDF

Availability: 4230 pieces

Current price of LQH2HPZ3R3MGRL is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

LQH2HPZ3R3MGRL Specifications

Type	Description
Series:	LQH2
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Type:	Wirewound
Material - Core:	Ferrite
Inductance:	3.3 µH
Tolerance:	±20%
Current Rating (Amps):	1.1 A
Current - Saturation (Isat):	1.23A
Shielding:	Shielded
DC Resistance (DCR):	270mOhm Max
Q @ Freq:	-
Frequency - Self Resonant:	70MHz
Ratings:	AEC-Q200
Operating Temperature:	-40°C ~ 105°C
Inductance Frequency - Test:	1 MHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	1008 (2520 Metric)
Supplier Device Package:	1008 (2520 Metric)
Size / Dimension:	0.098" L x 0.079" W (2.50mm x 2.00mm)
Height - Seated (Max):	0.039" (1.00mm)

Please confirm the specifications of the products when ordering.
