CDRH2D14NP-8R2NC

Part No :: CDRH2D14NP-8R2NC

Manufacturer: Sumida Corporation

Description: FIXED IND 8.2UH 800MA 281 MOHM

Catalog: Fixed Inductors

DataSheet: CDRH2D14NP-8R2NC PDF

Availability: 0 pieces

Current price of CDRH2D14NP-8R2NC is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

CDRH2D14NP-8R2NC Specifications

Type	Description
Series:	CDRH2D14
Package:	Tape & Reel (TR)
Part Status:	Active
Type:	-
Material - Core:	Ferrite
Inductance:	8.2 µH
Tolerance:	±30%
Current Rating (Amps):	800 mA
Current - Saturation (Isat):	800mA
Shielding:	Shielded
DC Resistance (DCR):	281mOhm Max
Q @ Freq:	-
Frequency - Self Resonant:	-
Ratings:	-
Operating Temperature:	-40°C ~ 100°C
Inductance Frequency - Test:	100 kHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	Nonstandard
Supplier Device Package:	-
Size / Dimension:	0.118" L x 0.118" W (3.00mm x 3.00mm)
Height - Seated (Max):	0.061" (1.55mm)

Please confirm the specifications of the products when ordering.
