NLCV32T-R15M-EFR

Part No :: NLCV32T-R15M-EFR

Manufacturer: TDK Corporation

Description: FIXED IND 150NH 2.6A 28.8 MOHM

Catalog: Fixed Inductors

DataSheet: NLCV32T-R15M-EFR PDF

Availability: 0 pieces

Current price of NLCV32T-R15M-EFR is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

NLCV32T-R15M-EFR Specifications

Type	Description
Series:	NLCV-EF
Package:	Tape & Reel (TR)
Part Status:	Active
Type:	Wirewound
Material - Core:	Ferrite
Inductance:	150 nH
Tolerance:	±20%
Current Rating (Amps):	2.6 A
Current - Saturation (Isat):	-
Shielding:	Unshielded
DC Resistance (DCR):	28.8mOhm Max
Q @ Freq:	10 @ 25.2MHz
Frequency - Self Resonant:	500MHz
Ratings:	-
Operating Temperature:	-40°C ~ 105°C
Inductance Frequency - Test:	25.2 MHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	1210 (3225 Metric)
Supplier Device Package:	1210
Size / Dimension:	0.126" L x 0.098" W (3.20mm x 2.50mm)
Height - Seated (Max):	0.094" (2.40mm)
