LQG15WZ91NG02D

Part No :: LQG15WZ91NG02D

Manufacturer: TOKO / Murata

Description: FIXED IND 91NH 160MA 2.3 OHM SMD

Catalog: Fixed Inductors

DataSheet: LQG15WZ91NG02D PDF

Availability: 0 pieces

Current price of LQG15WZ91NG02D is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

LQG15WZ91NG02D Specifications

Type	Description
Series:	LQG15
Package:	Tape & Reel (TR)
Part Status:	Active
Type:	Multilayer
Material - Core:	-
Inductance:	91 nH
Tolerance:	±2%
Current Rating (Amps):	160 mA
Current - Saturation (Isat):	-
Shielding:	Unshielded
DC Resistance (DCR):	2.3Ohm Max
Q @ Freq:	23 @ 250MHz
Frequency - Self Resonant:	900MHz
Ratings:	AEC-Q200
Operating Temperature:	-55°C ~ 125°C
Inductance Frequency - Test:	100 MHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	0402 (1005 Metric)
Supplier Device Package:	0402
Size / Dimension:	0.039" L x 0.020" W (1.00mm x 0.50mm)
Height - Seated (Max):	0.022" (0.55mm)
