B82442T1685J000

Image is for reference,
please contact us to get the real picture

Part No :: B82442T1685J000

Manufacturer: TDK EPCOS

Description: FIXED IND 6.8MH 65MA 60.3 OHM

Catalog: Fixed Inductors

DataSheet: B82442T1685J000 PDF

Availability: 0 pieces

Unit Price: ~~$0.63184~~

Current price of B82442T1685J000 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

B82442T1685J000 Specifications

Type	Description
Series:	SIMID
Package:	Tape & Reel (TR)
Part Status:	Active
Type:	Wirewound
Material - Core:	Ferrite
Inductance:	6.8 mH
Tolerance:	±5%
Current Rating (Amps):	65 mA
Current - Saturation (Isat):	125mA
Shielding:	Unshielded
DC Resistance (DCR):	60.3Ohm Max
Q @ Freq:	30 @ 252kHz
Frequency - Self Resonant:	600kHz
Ratings:	AEC-Q200
Operating Temperature:	-55°C ~ 150°C
Inductance Frequency - Test:	252 kHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	2-SMD, J-Lead
Supplier Device Package:	-
Size / Dimension:	0.220" L x 0.197" W (5.60mm x 5.00mm)
Height - Seated (Max):	0.209" (5.30mm)
