CBC2012T220M

Image is for reference,
please contact us to get the real picture

Part No :: CBC2012T220M

Manufacturer: TAIYO YUDEN

Description: FIXED IND 22UH 190MA 4.81 OHM

Catalog: Fixed Inductors

DataSheet: CBC2012T220M PDF

Availability: 3930 pieces

Unit Price: ~~$0.24000~~

Current price of CBC2012T220M is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

CBC2012T220M Specifications

Type	Description
Series:	CB, C Type
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Type:	Wirewound
Material - Core:	Ferrite
Inductance:	22 µH
Tolerance:	±20%
Current Rating (Amps):	190 mA
Current - Saturation (Isat):	170mA
Shielding:	Unshielded
DC Resistance (DCR):	4.81Ohm Max
Q @ Freq:	-
Frequency - Self Resonant:	16MHz
Ratings:	-
Operating Temperature:	-40°C ~ 105°C
Inductance Frequency - Test:	2.52 MHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	0805 (2012 Metric)
Supplier Device Package:	0805 (2012 Metric)
Size / Dimension:	0.079" L x 0.049" W (2.00mm x 1.25mm)
Height - Seated (Max):	0.057" (1.45mm)
