SRR0906-561YL

Part No :: SRR0906-561YL

Manufacturer: J.W. Miller / Bourns

Description: FIXED IND 560UH 280MA 2.7OHM SMD

Catalog: Fixed Inductors

DataSheet: SRR0906-561YL PDF

Availability: 0 pieces

Current price of SRR0906-561YL is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

SRR0906-561YL Specifications

Type	Description
Series:	SRR0906
Package:	Tape & Reel (TR)
Part Status:	Active
Type:	Wirewound
Material - Core:	Ferrite
Inductance:	560 µH
Tolerance:	±15%
Current Rating (Amps):	280 mA
Current - Saturation (Isat):	350mA
Shielding:	Shielded
DC Resistance (DCR):	2.7Ohm Max
Q @ Freq:	60 @ 796kHz
Frequency - Self Resonant:	3.2MHz
Ratings:	-
Operating Temperature:	-40°C ~ 125°C
Inductance Frequency - Test:	1 kHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	8-SMD, Gull Wing
Supplier Device Package:	-
Size / Dimension:	0.394" L x 0.374" W (10.00mm x 9.50mm)
Height - Seated (Max):	0.248" (6.30mm)

Please confirm the specifications of the products when ordering.
