784775212

Part No :: 784775212

Manufacturer: Würth Elektronik Midcom

Description: FIXED IND 120UH 670MA 470 MOHM

Catalog: Fixed Inductors

DataSheet: 784775212 PDF

Availability: 0 pieces

Current price of 784775212 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

784775212 Specifications

Type	Description
Series:	WE-PD2A
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Type:	Wirewound
Material - Core:	Ferrite
Inductance:	120 µH
Tolerance:	±20%
Current Rating (Amps):	670 mA
Current - Saturation (Isat):	810mA
Shielding:	Unshielded
DC Resistance (DCR):	470mOhm Max
Q @ Freq:	-
Frequency - Self Resonant:	6MHz
Ratings:	AEC-Q200
Operating Temperature:	-40°C ~ 125°C
Inductance Frequency - Test:	10 kHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	Nonstandard
Supplier Device Package:	7850
Size / Dimension:	0.307" L x 0.276" W (7.80mm x 7.00mm)
Height - Seated (Max):	0.217" (5.50mm)
