LQH32MN101J23L

Part No :: LQH32MN101J23L

Manufacturer: TOKO / Murata

Description: FIXED IND 100UH 80MA 7 OHM SMD

Catalog: Fixed Inductors

DataSheet: LQH32MN101J23L PDF

Availability: 23 pieces

Current price of LQH32MN101J23L is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

LQH32MN101J23L Specifications

Type	Description
Series:	LQH32
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Type:	Wirewound
Material - Core:	Ferrite
Inductance:	100 µH
Tolerance:	±5%
Current Rating (Amps):	80 mA
Current - Saturation (Isat):	-
Shielding:	Unshielded
DC Resistance (DCR):	7Ohm Max
Q @ Freq:	40 @ 796kHz
Frequency - Self Resonant:	8MHz
Ratings:	-
Operating Temperature:	-40°C ~ 85°C
Inductance Frequency - Test:	1 MHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	Nonstandard
Supplier Device Package:	1210 (3225 Metric)
Size / Dimension:	0.126" L x 0.098" W (3.20mm x 2.50mm)
Height - Seated (Max):	0.087" (2.20mm)
