CM322522-151KL

Part No :: CM322522-151KL

Manufacturer: J.W. Miller / Bourns

Description: FIXED IND 150UH 50MA 15 OHM SMD

Catalog: Fixed Inductors

DataSheet: CM322522-151KL PDF

Availability: 0 pieces

Current price of CM322522-151KL is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

CM322522-151KL Specifications

Type	Description
Series:	CM322522
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Type:	Wirewound
Material - Core:	Ferrite
Inductance:	150 µH
Tolerance:	±10%
Current Rating (Amps):	50 mA
Current - Saturation (Isat):	-
Shielding:	Unshielded
DC Resistance (DCR):	15Ohm Max
Q @ Freq:	20 @ 796kHz
Frequency - Self Resonant:	8MHz
Ratings:	-
Operating Temperature:	-40°C ~ 125°C
Inductance Frequency - Test:	796 kHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	Nonstandard
Supplier Device Package:	-
Size / Dimension:	0.126" L x 0.098" W (3.20mm x 2.50mm)
Height - Seated (Max):	0.087" (2.20mm)
