CB2016T470M

Part No :: CB2016T470M

Manufacturer: TAIYO YUDEN

Description: FIXED IND 47UH 240MA 3.12 OHM

Catalog: Fixed Inductors

DataSheet: CB2016T470M PDF

Availability: 0 pieces

Current price of CB2016T470M is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

CB2016T470M Specifications

Type	Description
Series:	CB
Package:	Tape & Reel (TR)
Part Status:	Active
Type:	Wirewound
Material - Core:	Ferrite
Inductance:	47 µH
Tolerance:	±20%
Current Rating (Amps):	240 mA
Current - Saturation (Isat):	110mA
Shielding:	Unshielded
DC Resistance (DCR):	3.12Ohm Max
Q @ Freq:	-
Frequency - Self Resonant:	11MHz
Ratings:	-
Operating Temperature:	-40°C ~ 105°C
Inductance Frequency - Test:	2.52 MHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	0806 (2016 Metric)
Supplier Device Package:	0806 (2016 Metric)
Size / Dimension:	0.079" L x 0.063" W (2.00mm x 1.60mm)
Height - Seated (Max):	0.071" (1.80mm)

Please confirm the specifications of the products when ordering.
