CD30D22HF-3R3MC

Part No :: CD30D22HF-3R3MC

Manufacturer: Sumida Corporation

Description: FIXED IND 3.3UH 1.56A 111 MOHM

Catalog: Fixed Inductors

DataSheet: CD30D22HF-3R3MC PDF

Availability: 0 pieces

Current price of CD30D22HF-3R3MC is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

CD30D22HF-3R3MC Specifications

Type	Description
Series:	CD30D22
Package:	Tape & Reel (TR)
Part Status:	Active
Type:	Wirewound
Material - Core:	Ferrite
Inductance:	3.3 µH
Tolerance:	±20%
Current Rating (Amps):	1.56 A
Current - Saturation (Isat):	1.76A
Shielding:	Unshielded
DC Resistance (DCR):	111mOhm Max
Q @ Freq:	-
Frequency - Self Resonant:	-
Ratings:	-
Operating Temperature:	-40°C ~ 125°C
Inductance Frequency - Test:	100 kHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	Nonstandard
Supplier Device Package:	-
Size / Dimension:	0.138" L x 0.118" W (3.50mm x 3.00mm)
Height - Seated (Max):	0.098" (2.50mm)

Please confirm the specifications of the products when ordering.
