WCLA2012V1-2R2-R

Part No :: WCLA2012V1-2R2-R

Manufacturer: PowerStor (Eaton)

VIGOR # :: 1633742

Description: FIXED IND 2.2NH 800MA 30 MOHM

Catalog: Fixed Inductors

DataSheet: WCLA2012V1-2R2-R PDF

Current price of WCLA2012V1-2R2-R is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

WCLA2012V1-2R2-R Specifications

Type	Description
Series:	WCLA2012V1
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Type:	Wirewound
Material - Core:	-
Inductance:	2.2 nH
Tolerance:	±10%
Current Rating (Amps):	800 mA
Current - Saturation (Isat):	-
Shielding:	Unshielded
DC Resistance (DCR):	30mOhm Max
Q @ Freq:	50 @ 1.5GHz
Frequency - Self Resonant:	8.5GHz
Ratings:	AEC-Q200
Operating Temperature:	-40°C ~ 125°C
Inductance Frequency - Test:	250 MHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	0805 (2012 Metric)
Supplier Device Package:	0805
Size / Dimension:	0.091" L x 0.067" W (2.30mm x 1.70mm)
Height - Seated (Max):	0.060" (1.52mm)

Please confirm the specifications of the products when ordering.
