LQW15AN25NG80D

Part No :: LQW15AN25NG80D

Manufacturer: TOKO / Murata

Description: FIXED IND 25NH 750MA 221 MOHM

Catalog: Fixed Inductors

DataSheet: LQW15AN25NG80D PDF

Availability: 0 pieces

Current price of LQW15AN25NG80D is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

LQW15AN25NG80D Specifications

Type	Description
Series:	LQW15
Package:	Tape & Reel (TR)
Part Status:	Active
Type:	Wirewound
Material - Core:	-
Inductance:	25 nH
Tolerance:	±2%
Current Rating (Amps):	750 mA
Current - Saturation (Isat):	-
Shielding:	Unshielded
DC Resistance (DCR):	221mOhm Max
Q @ Freq:	31 @ 250MHz
Frequency - Self Resonant:	4.1GHz
Ratings:	-
Operating Temperature:	-55°C ~ 125°C
Inductance Frequency - Test:	100 MHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	0402 (1005 Metric)
Supplier Device Package:	-
Size / Dimension:	0.039" L x 0.020" W (1.00mm x 0.50mm)
Height - Seated (Max):	0.024" (0.60mm)
