SRP7030-R68M

Part No :: SRP7030-R68M

Manufacturer: J.W. Miller / Bourns

Description: FIXED IND 680NH 15.5A 5.5MOHM SM

Catalog: Fixed Inductors

DataSheet: SRP7030-R68M PDF

Availability: 1205 pieces

Current price of SRP7030-R68M is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

SRP7030-R68M Specifications

Type	Description
Series:	SRP7030
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Type:	Wirewound
Material - Core:	Iron
Inductance:	680 nH
Tolerance:	±20%
Current Rating (Amps):	15.5 A
Current - Saturation (Isat):	23A
Shielding:	Shielded
DC Resistance (DCR):	5.5mOhm Max
Q @ Freq:	-
Frequency - Self Resonant:	-
Ratings:	-
Operating Temperature:	-55°C ~ 150°C
Inductance Frequency - Test:	100 kHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	Nonstandard
Supplier Device Package:	-
Size / Dimension:	0.307" L x 0.276" W (7.80mm x 7.00mm)
Height - Seated (Max):	0.126" (3.20mm)
