SDR1005-1R5ML

Part No :: SDR1005-1R5ML

Manufacturer: J.W. Miller / Bourns

Description: FIXED IND 1.5UH 6.5A 9 MOHM SMD

Catalog: Fixed Inductors

DataSheet: SDR1005-1R5ML PDF

Availability: 137 pieces

Unit Price: ~~$0.84000~~

Current price of SDR1005-1R5ML is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

SDR1005-1R5ML Specifications

Type	Description
Series:	SDR1005
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Type:	Wirewound
Material - Core:	Ferrite
Inductance:	1.5 µH
Tolerance:	±20%
Current Rating (Amps):	6.5 A
Current - Saturation (Isat):	8A
Shielding:	Unshielded
DC Resistance (DCR):	9mOhm Max
Q @ Freq:	50 @ 3MHz
Frequency - Self Resonant:	95MHz
Ratings:	-
Operating Temperature:	-40°C ~ 125°C
Inductance Frequency - Test:	1 kHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	Nonstandard
Supplier Device Package:	-
Size / Dimension:	0.500" L x 0.394" W (12.70mm x 10.00mm)
Height - Seated (Max):	0.197" (5.00mm)
