S1812R-274G

Part No :: S1812R-274G

Manufacturer: API Delevan

Description: FIXED IND 270UH 135MA 11 OHM SMD

Catalog: Fixed Inductors

DataSheet: S1812R-274G PDF

Availability: 0 pieces

Current price of S1812R-274G is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

S1812R-274G Specifications

Type	Description
Series:	S1812R
Package:	Tape & Reel (TR)
Part Status:	Active
Type:	-
Material - Core:	Ferrite
Inductance:	270 µH
Tolerance:	±2%
Current Rating (Amps):	135 mA
Current - Saturation (Isat):	-
Shielding:	Shielded
DC Resistance (DCR):	11Ohm Max
Q @ Freq:	40 @ 790kHz
Frequency - Self Resonant:	4MHz
Ratings:	-
Operating Temperature:	-55°C ~ 125°C
Inductance Frequency - Test:	790 kHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	1812 (4532 Metric)
Supplier Device Package:	1812 (4532 Metric)
Size / Dimension:	0.189" L x 0.134" W (4.80mm x 3.40mm)
Height - Seated (Max):	0.134" (3.40mm)
