PQ2617BHA-220K

Image is for reference,
please contact us to get the real picture

Part No :: PQ2617BHA-220K

Manufacturer: J.W. Miller / Bourns

Description: FIXED IND 22UH 28A 2.5 MOHM SMD

Catalog: Fixed Inductors

DataSheet: PQ2617BHA-220K PDF

Availability: 65 pieces

Unit Price: ~~$4.17000~~

Current price of PQ2617BHA-220K is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

PQ2617BHA-220K Specifications

Type	Description
Series:	PQ2617BHA
Package:	Tray
Part Status:	Active
Type:	Wirewound
Material - Core:	Ferrite
Inductance:	22 µH
Tolerance:	±10%
Current Rating (Amps):	28 A
Current - Saturation (Isat):	14A
Shielding:	Shielded
DC Resistance (DCR):	2.5mOhm Max
Q @ Freq:	-
Frequency - Self Resonant:	15MHz
Ratings:	AEC-Q200
Operating Temperature:	-40°C ~ 155°C
Inductance Frequency - Test:	100 kHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	Nonstandard
Supplier Device Package:	-
Size / Dimension:	1.098" L x 0.780" W (27.90mm x 19.80mm)
Height - Seated (Max):	0.748" (19.00mm)

Please confirm the specifications of the products when ordering.
