SCH74-470

Part No :: SCH74-470

Manufacturer: Signal Transformer

Description: FIXED IND 47UH 1.55A 230 MOHM

Catalog: Fixed Inductors

DataSheet: SCH74-470 PDF

Availability: 0 pieces

Unit Price: ~~$0.00000~~

Current price of SCH74-470 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

SCH74-470 Specifications

Type	Description
Series:	SCH74
Package:	Tape & Reel (TR)
Part Status:	Obsolete
Type:	Wirewound
Material - Core:	-
Inductance:	47 µH
Tolerance:	±10%
Current Rating (Amps):	1.55 A
Current - Saturation (Isat):	1.2A
Shielding:	Unshielded
DC Resistance (DCR):	230mOhm Max
Q @ Freq:	-
Frequency - Self Resonant:	-
Ratings:	-
Operating Temperature:	-40°C ~ 125°C
Inductance Frequency - Test:	1 kHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	Nonstandard
Supplier Device Package:	-
Size / Dimension:	0.315" L x 0.287" W (8.00mm x 7.30mm)
Height - Seated (Max):	0.205" (5.20mm)
