NP04SZB150M

Image is for reference,
please contact us to get the real picture

Part No :: NP04SZB150M

Manufacturer: TAIYO YUDEN

Description: FIXED IND 15UH 950MA 250 MOHM

Catalog: Fixed Inductors

DataSheet: NP04SZB150M PDF

Availability: 0 pieces

Unit Price: ~~$0.00000~~

Current price of NP04SZB150M is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

NP04SZB150M Specifications

Type	Description
Series:	N, P Type
Package:	Tape & Reel (TR)
Part Status:	Obsolete
Type:	-
Material - Core:	Ferrite
Inductance:	15 µH
Tolerance:	±20%
Current Rating (Amps):	950 mA
Current - Saturation (Isat):	950mA
Shielding:	Shielded
DC Resistance (DCR):	250mOhm Max
Q @ Freq:	-
Frequency - Self Resonant:	12MHz
Ratings:	-
Operating Temperature:	-25°C ~ 105°C
Inductance Frequency - Test:	1 kHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	Nonstandard
Supplier Device Package:	-
Size / Dimension:	0.197" L x 0.197" W (5.00mm x 5.00mm)
Height - Seated (Max):	0.079" (2.00mm)
