IM02BH331J

Part No :: IM02BH331J

Manufacturer: Vishay / Dale

VIGOR # :: 8196336

Description: FIXED IND 330UH 45MA 28 OHM TH

Catalog: Fixed Inductors

DataSheet: IM02BH331J PDF

Country of origin: -

Date code: -

IM02BH331J Specifications

Type	Description
Series:	IM
Package:	-
Part Status:	Obsolete
Type:	Molded
Material - Core:	Ferrite
Inductance:	330 µH
Tolerance:	±5%
Current Rating (Amps):	45 mA
Current - Saturation (Isat):	-
Shielding:	Unshielded
DC Resistance (DCR):	28Ohm Max
Q @ Freq:	30 @ 790kHz
Frequency - Self Resonant:	7MHz
Ratings:	-
Operating Temperature:	-55°C ~ 125°C
Inductance Frequency - Test:	790 kHz
Features:	-
Mounting Type:	Through Hole
Package / Case:	Axial
Supplier Device Package:	-
Size / Dimension:	0.095" Dia x 0.250" L (2.42mm x 6.35mm)
Height - Seated (Max):	-
