S0603-3N3G1S

Part No :: S0603-3N3G1S

Manufacturer: API Delevan

VIGOR # :: 8198958

Description: FIXED IND 3.3NH 700MA 100 MOHM

Catalog: Fixed Inductors

DataSheet: S0603-3N3G1S PDF

Country of origin: -

Date code: -

S0603-3N3G1S Specifications

Type	Description
Series:	S0603
Package:	Bulk
Part Status:	Active
Type:	Wirewound
Material - Core:	Alumina
Inductance:	3.3 nH
Tolerance:	±2%
Current Rating (Amps):	700 mA
Current - Saturation (Isat):	-
Shielding:	Unshielded
DC Resistance (DCR):	100mOhm Max
Q @ Freq:	18 @ 250MHz
Frequency - Self Resonant:	6GHz
Ratings:	-
Operating Temperature:	-55°C ~ 125°C
Inductance Frequency - Test:	250 MHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	0603 (1608 Metric)
Supplier Device Package:	0603 (1608 Metric)
Size / Dimension:	0.062" L x 0.035" W (1.58mm x 0.89mm)
Height - Seated (Max):	0.040" (1.02mm)
